AGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser (45 LPM)

AGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser (45 LPM)
AGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser (45 LPM) AGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser FeaturesAGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser Run StatusAGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser RequirementsAGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser CertsAGLED-12G UVC-LED Ultra Violet (UV) Water Steriliser Kit
Product ID:
1016

Price:£394.98

Inlet/Outlet Connections




AGLED-12G is a next generation, compact, high-flow UVC LED water treatment system developed for point-of-entry water disinfection. With a maximum flow capacity of 12 GPM / 45 LPM, it is suitable for whole-house water treatment, private well water systems, light-commercial applications and OEM water purification equipment.

Unlike chemical disinfection methods, UVC treatment does not require disinfectant dosing and does not add treatment chemicals to the water. The compact 24 V DC architecture also makes AGLED-12G easy to integrate into complete residential and commercial water treatment systems

Features:
New LED advanced technology
5,000 hours lifespan
Automatic switch on/off feature (water flow controls on/off)
Instant usage (no need to wait for lamp to heat up)
UVC Working indicator
99.999% disinfection rate
Compact design
Money and energy saving

High-Flow UVC LED Disinfection

AGLED-12G provides a maximum flow rate of up to 12 GPM (45 LPM), allowing one compact UVC LED unit to serve whole-house and light-commercial applications.It is designed to provide a final microbial disinfection barrier after appropriate upstream water treatment

Flow-Activated Operation

The system has a startup flow of: 4 LPM
The UVC LED module can operate according to actual water demand, making the system particularly suitable for intermittent residential water use.Compared with systems that require continuous lamp operation, flow-activated UVC LED technology helps reduce unnecessary operating time.

270-280 nm UVC LED Technology

AGLED-12G uses UVC LEDs operating within the 270-280 nm wavelength range. As water passes through the reactor, UVC energy acts on susceptible microorganisms and interferes with their ability to reproduce.This provides a physical microbial disinfection process without chemical disinfectant dosing.

Low-Voltage 24 V DC Operation

AGLED-12G operates with:
Input voltage: 24 V DC
Rated power: 16 W
The low-voltage architecture makes the system convenient for integration into residential water treatment equipment and OEM purification systems.

Compact Point-of-Entry Design

Despite providing a maximum flow rate of 12 GPM, AGLED-12G maintains a compact product size of approximately: Ø63.5 × 315 mm
The slim cylindrical structure helps reduce installation-space requirements in whole-house water treatment systems.

Flexible 1-Inch Connection

The reactor uses:
G1 Female Inlet / Outlet
It can be used with suitable 1-inch NPT1 / PT1 / G1 / R1 male-thread fittings, allowing easier integration into different plumbing systems and international projects.

Designed for Frequent Switching

AGLED-12G is designed for more than 100,000 switching cycles This makes the UVC LED system well suited to flow-activated applications where the module may switch on and off frequently according to water demand.

Model-Specific Disinfection Performance

Under the specified SGS report test conditions, AGLED-12G achieved 99.999% E.coli reduction at 12 GPM
Actual field performance may vary depending on water quality, flow rate, UV transmittance, turbidity and overall system configuration.

{Technical}

Model: AGLED-12G
Maximum Flow Rate: 12 GPM / 45 LPM
Startup Flow:> 4 L/min
Maximum Inlet Pressure: 0.8 MPa / 8 bar / 116 psi
Water Temperature: 1–45°C / 34–113°F
Inlet / Outlet: G1 Female
Compatible Connection:1-inch NPT1 / PT1 / G1 / R1 Male Thread
Product Dimension: Ø63.5 × 315 mm
Net Weight: 2.4 kg
Gross Weight: 2.6 kg
Input Voltage: 24 V DC
Output Current: 600 mA
Input Current: 0.7 A
Rated Power: 16 W
UVC Radiant Output: 500 mW
UVC Wavelength: 270-280 nm
L70 Service Life: 5,000 hours
Switch Cycles: > 100,000
